LIQUIfit™ fittings offer an innovative alternative for water applications. No fluid contamination occurs, and environmental protection is guaranteed. Typical applications for these fittings include water purification systems, water dispensers, drink dispensers, cooling systems, food processing, and CO2. Connect - Push the tubing until it bottoms out. Holding and sealing are accomplished instantaneously. Disconnect - First, depress the manual release button, then pull the tubing out of the fitting.
- Polypropylene
- D-shaped EPDM seals
- SS gripping ring eliminates locking clips
- Self-cleaning, scale-resistant polysulfone ball
- The compact design facilitates the tightest tube bends
- Working pressure @ 73°F: 150 psi (1/4" & 3/8")
- Temperature range: 35°F to 200°F
- Meets FDA & NSF 51 & 61 standards
- Dimensions: 2.40" L x 1.40" Hgt.
- Thru hole: 0.19"
