NS1 Series couplings compact, closed-system design is packed full of features including non-spill shutoff valves that ensure drip-free disconnects and eliminate the need to purge air from the system. The smallest plastic non-spill coupling on the market, NS1 is perfect for applications with tubing from 1/8" and smaller. The ultra-low air inclusion minimizes contaminants and eliminates the need to purge air bubbles from the system. Chemically resistant materials provide reliable strength and performance in a range of applications.
- Polypropylene main components & PEEK® thumb latch
- 316 SS spring & EPDM O-rings
- Non-spill, closed system for drip-free disconnect
- Eliminate the need to purge air from the system
- Allows tubing rotation, preventing kinks
- Ergonomic, user-friendly interface
- Enables secure, reliable connection & disconnection
- Reliable strength & performance
- Pressure rating: vacuum to 15 psi, 1.0 bar
- Temperature range: 32°F to 120°F
