The battery-operated in-line plastic paddle wheel flow meter has been designed for demanding industrial applications. The TKB series paddle wheel flow transmitter has been engineered to provide long-term accurate flow measurement for corrosive and non-corrosive liquids. The all-plastic in-line flow meter is equipped with a 360° rotatable vivid backlit LCD display showing both Flow rate & flow total. The re-engineered low-drag, fluid-dynamic design of the paddle wheel allows it to stand alone as the industry's most accurate flow meter. The TKB series plastic flow meters incorporate an all-new re-designed air-foil-designed rotor that reduces turbulence and drag as the liquid passes by up to 92%. The zirconium rotor pin has been polished to a mirror finish and provides superior chemical and wear resistance over a metal pin. It should be noted that the rotor has been outfitted with two ceramic bushings. This design allows for much finer rotor pin to paddle alignment and significantly reduces paddle wobble that occurs without bushings. The paddle wheel flow sensors incorporate an ETFE paddle coupled with a zirconium ceramic rotor pin and bushings. The TKB series battery-operated liquid flow meter is the industry's longest-lasting paddle wheel flow meter and comes with a lifetime warranty on the paddle wheel assembly. Applications include liquid chemical flow measurement, filtration systems, water/wastewater monitoring, industrial chemical distribution, process chemical skids, liquid consumption, and discharge verification.
- PVC, polypropylene, or PVDF body
- ETFE paddle wheel; Zirconium ceramic rotor & bushings
- Battery operated back-lit LCD display
- Flow rate & total
- Lifetime warranty on paddle assembly
- Accuracy: ±0.5%
- Chemical resistant
- No programming
- True union design
- 360° rotatable display
